5: 5A at 250VAC

None: Pin plunger

None: 1.47N

10: 10A at 250VAC

Z: Hinge lever

F: 0.59N

W: Simulated roller lever

G: Hinge roller lever

4. Contact Form

5. Terminals

6. Shell Material

None: SPDT

None: Solder terminals

None: PMC

2: SPST-NC

T: Quick-connect terminal (#110)

P: PBT

3: SPST-NO

D: PCB terminals (Even pitch)

D1: Left angle PCB terminals

D2: Right angle PCB terminals

AC125V

—

5A

AC250V

10A

5A

30VDC

—

5A

AC125V

—

5A

AC250V

0.5A

5A

30VDC

—

5A

AC125V

10A

5(2)A

AC250V

10A

5(2)A

Allowable operating speed

0.1mm~1000m/s

Operatingfrequency

Mechanical

400 times/min

Electrical

30 times/min

Insulation resistance

Min.:100MΩ

Contact resistance

Max.:50mΩ

Dielectricstrength

BTW same polarity terminals

AC1000V 50/60Hz 1min

BTW current-carrying parts

AC1500V 50/60Hz 1min

BTW terminal & metal parts

AC1500V 50/60Hz 1min

Vibrationresistance

Malfunction

10~55Hz amplitude 1.5mm

Shockresistance

Durable

1000m/s

Malfunction

300m/s

Expected lifelife

Mechanical life

1x10 6 (60 operations/minute)

Electrical life

1x10 5 (30 operations/minute)

Protection degree

IEC IP40

Ambient operation temperature

-20℃~+125℃

Ambient humidity

60%RH

Weight

Approx. 1.6 g pin plunger type

Specification

Rivet

Material

Silver alloy

Gap (Standard value)

0.5mm

Inrushcurrent

NC

20A max.

20A max.

NO

15Amax.

10SAmax

Minimum applicable load

160mA at 5VDC

Resistive load

Lamp load

Inductive load

Motor load

NC

NO

NC

NO

NC

NO

NC

NO

AC125V

5A(10A)

1.5A

0.7A

3A

2.5A

1.3A

AC250V

3A(10A)

1A

1.5A

2A

1.5A

0.8A

DC8V

5A(10A)

2A

5A

4A

3A

DC14V

5A(10A)

2A

4A

3A

DC30V

4A

2A

3A

3A

DC125V

0.4A

0.05A

0.4A

0.05A

DC250V

0.2A

0.03A

0.2A

0.03A

OF max.

0.49N

0.49N

0.16N

RF min.

0.06N

0.06N

0.02N

OT min.

1.0mm

1.2mm

1.2mm

MD max.

1.0mm

0.8mm

0.8mm

FP max.

19.3mm

OP

14.5±0.8mm
