②

Part Number

③

 Coil Voltage

④

D= Double Coil; S= Single Coil

⑤

100=100A

Dielectric

Strength

Between Coil & Contacts

Between Open Contacts

Pole & Pole

4000VAC 1min

2000VAC 1 min

4000VAC 1min

 Operate Time

30msec. Max.

 Release Time

30msec. Max.

Shock

resistance

 Functional

 Destructive

98m/S2

980m/S2

Vibration resistance

10~55Hz 1.5mm

Humidity

5%~85%RH

 Ambient temperature

-40~+85℃

 Temination

Fast connection

 Unit weight

200g

Constrution

Dust protected

Contact material

AgSnO2

 Contact resistance (1A 6VDC)

(Test point within 5mm distance from the casing )

Max: 1.0 mΩ

 Contact Rating

100A 250VAC

 Max. Switching Current

100A

 Max. Switching Voltage

277VAC

 Max. Switching Power

27700VA

 Mechanical life

1×105

 Electrical  life ( Resistive)

1×104

UC3

230VAC

100A

10s on /20s off

COS ∅ =1

COS∅ =0.5

5000

(Total:10000) 5000

 Single coil

6

≤ 4.5

≥ 100

7.2±10%

9

≤ 6.8

≥ 100

16.2±10%

12

≤  9

≥ 100

28.8±10%

24

≤  18

≥ 100

115.2±10%

 Double coil

6

≤ 4.5

≥

100

2×3.6±10%

9

≤ 6.8

≥

100

2×8.1±10%

12

≤  9

≥

100

2×14.4±10%

24

≤ 18

≥

100

2×57.6±10%
